Seamless Steel Pipe
JIS Standard Steel Pipe
JIS standard steel pipe refers to steel pipe that adhere to the standards set by the japanese industrial standards (JIS).
JIS pipes are steel pipe that have been created by JIS and meets certain performance requirements. JIS standard pipe covers various types of seamless pipes, including alloy steel, stainless steel, and carbon steel. These standards specify the technical requirements, dimensions, materials, and testing methods for seamless pipes. Some commonly referenced JIS standards for seamless pipes include JIS g3455, JIS g3452, JIS g3429, JIS g3441, JIS g3444, JIS g3445, and JIS g3454.
Specification
Standard Scope:
|
Standard |
Grade |
Uses |
Sizes |
|
JIS G3429 |
STH38, STH55, STH67 |
Seamless Steel Tubes in High Pressure Gas Cylinder |
/ |
|
JIS G3439 |
STO-G, STO-H, STO-J, STO-N, STO-C, STO-D, STO-E |
Seamless Steel Oil Well, Casing, Tubing and Drill Pipe |
/ |
|
JIS G3441 |
SCr 420TK, SCM415TK, SCM418TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK |
Alloy Steel Tubes for General Structural Purpose |
21.7-1016.0mm |
|
JIS G3444 |
STK 30, STK 41, STK 50, STK 51, STK 55 |
Carbon Steel Pipe for General Structural Purpose |
/ |
|
JIS G3445 |
STKM11A,STKM12A, STKM12B, STKM12C, STKM13A, STKM13B, STKM13C, STKMI4A, STKM14B, STKM14C, STKM15A, STKM18C, STKM16A, STKM18C, STKM17A, STKM17C, STKM18A, STKM18B, STKM18C |
Carbon Steel Tubes for Machine Structural Purposes |
10.5-660.4 mm |
|
JIS G3454 |
STPG 38, STPG 42 |
Carbon Steel Pipes for Pressure Service |
10.5-660.4 mm |
|
JIS G3455 |
STS 38, STS 42, STS 49 |
Carbon Steel Pipes for High Pressure Service |
10.5-660.4 mm |
|
JIS G3456 |
STPT 38, STPT 42, STPT 49 |
Carbon Steel Pipes for High Temperature Service |
10.5-660.4 mm |
|
JIS G3458 |
STPA 12, STPA 20, STPA 22, STPA 23, STPA 24, STPA 25, STPA 26 |
Alloy Steel Pipes for Service |
10.5-660.4 mm |
|
JIS G3460 |
STPL 39, STPL 46, STPL 70 |
Steel Pipes for Low Temperature Service |
15.9-139.8 mm |
|
JIS G3461 |
STB 35, STB 42, STB 52 |
Carbon Steel Boiler and Heat Exchanger Tubes |
15.9-139.8 mm |
|
JIS G3462 |
STBAl2, STBAM, STBA20, STBA22, STBA23, STBA24, STBA25, STEA26 |
Alloy Steel Boiler and Heat Exchanger Tubes |
15.9-139.8 mm |
|
JIS G3464 |
STBL 39, STBL46, STBL 70 |
Steel Heat Exchanger Tubes for Low Temperature Service |
15.9-139.8 mm |
|
JIS G3465 |
STM-055, STM-C65, STM-R60, STM-1170, STM-1180, STM-R85 |
Seamless Steel Tubes for Drilling |
Casing: 43-142mm / Hollow Pipes: 34-180mm / Drilling:33.5-50mm |
|
JIS G3467 |
STF 42, STFAl2, STFA22, STFA23, 5TFA24, STFA23, STFA26 |
Steel Tubes for Fired Heater |
60.5-267.4mm |
Tolerance of JIS seamless pipe:
Tolerance on Outside Diameter in JIS G3441, G3444, G3445
|
Standard |
Tolerance on outside diameter (mm) |
|
|
JIS G3441 |
=50 |
±0.5 |
|
>50 |
±1% |
|
|
JIS G3441 |
<50 |
±0.25 |
|
>50 |
±0.5% |
|
|
JIS G3441 |
<25 |
±0.12 |
|
>25-40 |
±0.15 |
|
|
>40-50 |
±0.18 |
|
|
>5:.60 |
±0.20 |
|
|
>60-70 |
±0.23 |
|
|
>70-80 |
±0.25 |
|
|
>80-90 |
±0.30 |
|
|
>90-100 |
±0.40 |
|
|
>100 |
±0.5% |
|
|
JIS G3441 |
<13 |
±0.25 |
|
>13-25 |
±0.40 |
|
|
>25-40 |
±0.60 |
|
|
>40-65 |
±0.80 |
|
|
>65-90 |
±1.00 |
|
|
>90-140 |
±1.20 |
|
|
>140 |
By agreement |
|
Tolerance on Wall Thickness in JIS G3441, G3444, G3445
|
Standard |
Tolerance on wall thickness (mm) |
|
|
JIS G3441 |
<=4 |
-0.5,+0.6 |
|
>4 |
-12.5%, +15% |
|
|
JIS G3441 |
<=3 |
±0 .3 |
|
>3 |
±10% |
|
|
JIS G3441 |
<=2 |
±0.15 |
|
>2 |
±8% |
|
Tolerance on Outside Diameter and Wall Thickness in JIS G3454
|
Process |
Tolerance on outside diameter |
Tolerance on wall thickness |
||
|
|
<40A |
±0.5mm |
<=4mm |
+0.6mm |
|
>50A, <125A |
±1% |
|||
|
Hot Rolled |
150A |
±1.6mm |
>4mm |
+15% |
|
>200A |
±0.8% |
|||
|
More than 350mm,the |
||||
|
Cold Drawn |
<25A |
±0.3mm |
<=3mm |
±0.3mm |
|
>32A |
±0.8% |
>3mm |
±10% |
|
|
But more than 350mm, the |
||||
Tolerance on Outside Diameter and Wall Thickness in JIS G3455, G3456, G3458, G3460
|
Process |
Tolerance on outside diameter |
Tolerance on wall thickness |
||
|
Hot Rolled |
<=50mm |
±0.5mm |
<=4mm |
±0.5mm |
|
>50-160mm |
±1% |
|||
|
>160-200mm |
±1.6mm |
>4mm |
±12.5% |
|
|
>200mm |
±0.8% |
|||
|
More that 350mm, the |
||||
|
Cold Drawn |
<=40mm |
±0.3mm |
<=2mm |
±0.2mm |
|
>40mm |
±0.8% |
>2mm |
±10% |
|
|
More than 350 mm the |
||||
Tolerance on Outside Diameter in JIS G3461, G3462, G3464
|
O.D. |
Tolerance on outside diameter |
||||
|
Hot rolled seamless pipes |
Seamless pipes through quench and normalized |
Cold drawn seamless pipes throng, the hot treatment except quench and normalized |
Electric welded pipes except cold drawn |
Cold drawn electric welded pipes |
|
|
mm |
|||||
|
<=25 |
+0.4 |
±0.25 |
±0.10 |
±0.15 |
±0.10 |
|
>25.40 |
±0.25 |
±0.15 |
±0.20 |
±0.15 |
|
|
>40-50 |
±0.25 |
±0.20 |
±0.25 |
±0.20 |
|
|
>50.60 |
±0.25 |
±0.25 |
±0.30 |
±0.25 |
|
|
>60-80 |
±0.30 |
±0.30 |
±0.40 |
±0.30 |
|
|
>80.100 |
±0.40 |
±0.40 |
-0.60,+0.40 |
±0.40 |
|
|
>100-120 |
+0.4 |
-0.60,+0.40 |
-0.60,+0.40 |
-0.80,+0.40 |
-0.60,+0.40 |
|
>120-160 |
-0.80,+0.40 |
-0.80,+0.40 |
-1.00,+0.40 |
-0.80,+0.40 |
|
|
>160-200 |
-1.8,+0.4 |
-1.20,+0.40 |
-1.20,+0.40 |
-1.20,+0.40 |
-1.20,+0.40 |
|
>200 |
-2.4,+0.4 |
-1.60,+0.40 |
-1.60,+0.40 |
-1.60,+0.40 |
-1.60,+0.40 |
Tolerance on Wall Thickness in JIS G3461, G3462, G3464
|
Wall |
Hot rolled seamless pipe |
Cold drawn seamless pipe |
Electric welded pipe |
|||
|
O.D（mm） |
O.D（mm） |
O.D（mm） |
||||
|
<=100 |
>100 |
<=40 |
>40 |
<=40 |
>40 |
|
|
(%) |
||||||
|
<=2 |
– |
– |
-0,+0.4mm |
+22 |
-0,+0.3mm |
+18 |
|
>2-2.4 |
-0,+40 |
– |
+20 |
+18 |
||
|
>2.4-3.8 |
-0,+35 |
-0,+35 |
||||
|
>3.8-4.6 |
-0,+23 |
-0,+33 |
||||
|
>4.6 |
-0,+28 |
-0,+28 |
||||
Tolerance on the Length in JIS G3461, G3462, G3464
|
Item |
Tolerance an length |
|
|
OD<50mm |
<7m |
-0, +7mm |
|
>=7m |
Every 3m increase in length, the plus tolerance be increased by 3mm with a maximum of 15mm |
|
|
OD>=50mm |
<7m |
-0, +10mm |
|
>=7m |
Every 3m increase in length, the plus tolerance be increased by 3mm with a maximum of 15mm |
|
|
OD: Outside Diameter |
||
Tolerance on Outside Diameter in JIS G3465
|
Process |
Tolerance on outside diameter (mm) |
|
|
Hot Rolled |
<=50 |
±0.5 |
|
>50 |
±1% |
|
|
Cold Drawn |
<=40 |
±0.2 |
|
>40 |
±0.5% |
|
JIS Number and Corrensponding Foreign Standards
|
JIS |
ASTM |
BS |
DIN |
NF |
ISO |
Index Number |
||||||||||||
|
Standard Number |
Grade |
Tupe |
Standard Number |
Grade |
Tupe |
Standard Number |
Grade |
Tupe |
Standard Number |
Grade |
Tupe |
Standard Number |
Grade |
Tupe |
Standard Number |
Grade |
Tupe |
|
|
G3456 |
STPT370 |
C |
A106 |
GrA |
C |
3602 |
HFS360 |
C |
17175 |
St35.8 |
C |
A49-211 |
TU37b |
C |
2604/2 |
TS5 |
C |
C004 |
|
|
|
|
|
|
" |
CFS360 |
C |
17177 |
St37.8 |
C |
A49-213 |
TU37c |
C |
2604/3 |
TW9H |
C |
|
|
|
|
|
|
|
|
" |
ERW360 |
C |
|
|
|
A49-243 |
TU37c |
C |
|
|
|
|
|
|
|
|
|
|
|
" |
CEW360 |
C |
|
|
|
|
|
|
|
|
|
|
|
|
|
STPT410 |
C |
A106 |
GrB |
C |
3602 |
HFS410 |
C |
17175 |
St45.8 |
C |
A49-211 |
TU42b |
C |
2604/2 |
TS9H |
C |
|
|
|
|
|
|
|
" |
CFS410 |
C |
17177 |
St42.8 |
C |
A49-213 |
TU42c |
C |
|
|
|
|
|
|
|
|
|
|
|
" |
ERW410 |
C |
|
|
|
A49-243 |
TU42c |
C |
|
|
|
|
|
|
|
|
|
|
|
" |
CEEW410 |
C |
|
|
|
|
|
|
|
|
|
|
|
|
|
STPT480 |
C |
A106 |
GrC |
C |
3602 |
HFS460 |
C |
|
|
|
A49-211 |
TU48b |
C |
2604/2 |
TS14 |
C |
|
|
|
|
|
|
|
" |
CFS460 |
C |
|
|
|
A49-213 |
TU48c |
C |
|
|
|
|
|
|
|
|
|
|
|
" |
ERW460 |
C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
" |
CEEW460 |
C |
|
|
|
|
|
|
|
|
|
|
|
Other Range of JIS standards for steel pipes:
JIS seamless pipe according to alloy, stainless steel or carbon. It tests steel’s properties, hardness, resistance to corrosion, pitting, heat treating processes and others. The results are listed in a main JIS steel grade for steel pipe as below.
JIS G3439
Seamless Steel Oil Well, Casing, Tubing and Drill Pipe
Steel grade: STO-G, STO-H, STO-J, STO-N, STO-C, STO-D, STO-E
Application: Seamless Steel Oil Well, Casing, Tubing and Drill Pipe
JIS G3441
Steel grade:SCr 420TK, SCM415TK, SCM418TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK
Application：Alloy Steel Tubes for General Structural Purpose
JIS G3444
Steel grade: STK 30, STK 41, STK 50, STK 51, STK 55
Application: Carbon Steel Tubes for General Structural Purpose
Dimension Range: 21.7-1016.0 mm
Application: Carbon Steel Tubes for Machine Structural Purposes
JIS G3455
Steel grade: STS 38, STS 42, STS 49
Application: Carbon Steel Pipes for High Pressure Service
Dimension Range: 10.5-660.4 mm
JIS G3456
Steel grade: STPT 38, STPT 42, STPT 49
Application: Carbon Steel Pipes for High Temperature Service
Dimension Range:10.5-660.4 mm
JIS G3460
Steel grade:STPL 39, STPL 46, STPL 70
Application: Steel Pipes for Low Temperature Service
Dimension Range:10.5-660.4 mm
JIS G3464
Steel grade: STBL 39, STBL46, STBL 70
Application: Steel Heat Exchanger Tubes for Low Temperature Service
Dimension Range: 15.9-139.8 mm
JIS G3465
Steel grade: STM-055, STM-C65, STM-R60, STM-1170, STM-1180, STM-R85
Application: Seamless Steel Tubes for Drilling
Dimension Range: Casing: 43-142mm / Hollow Pipes: 34-180mm / Drilling:33.5-50mm
JIS G3467
Steel grade: STF 42, STFAl2, STFA22, STFA23, 5TFA24, STFA23, STFA26
Application:Steel Tubes for Fired Heater
Dimension Range:60.5-267.4mm
JIS G3101 SS400
JIS G 3101 SS400 is one of the most commonly used hot rolled general structural steel.
SS400 is a Japanese brand of ordinary steel products
Process
b) Pipes are normally as manufactured. Cold-finished tubes shall be annealed after manufacture.
c) Both ends of pipes with a nominal diameter of 300A or smaller shall have threaded or plain ends, and pipes with a nominal diameter of 350A or larger shall have plain ends. However, if the orderer specifies the bevel end, the shape shall be according to the agreement between the parties to delivery.
d) When pipes are manufactured by electric resistance welding, external and internal weld beads shall be removed so as to smoothly follow the shape of the pipe unless otherwise specified. However, if it is difficult to remove the internal weld bead, it may be left as it is.
e) In the case of a threaded pipe, both ends shall be tapered according to JIS B 0203, and one joint according to JIS B 2301 or JIS B 2302 (hereinafter referred to as a socket) shall be screwed into one end. The unscrewed end of the socket shall be protected by a thread protection ring or other suitable means. However, if specified by the purchaser, the socket may be omitted. Inspection of tapered threads shall be in accordance with JIS B 0253.
f) If zinc plating is used, it shall be done before threads are machined into pipes and sockets. In this case, the black tubes and sockets that have passed the inspection are thoroughly cleaned by blasting, pickling, etc., and then galvanized by the hot-dip galvanizing method.
g) The zinc used for galvanizing shall be JIS H 2107 distilled zinc bare metal class 1 or zinc with equivalent or higher quality.
h) Other general matters for zinc plating shall be in accordance with JIS H 8641.
Packing
-
OD 219mm and above (Loose) ： Loose + pipe cap + two nylon slings
-
OD below 219mm (Bundled) ：Hexagonal packing + steel belts bundled (3 steel belts at both ends & 2 steel belts in the middle) woven bag under the st
