Reducer

Reducer Type:

concentric reducer, eccentric reducer

Material:

carbon steel --- astm a234 wpb/wpc, astm a105/a106/a53/a283-d, api 5l gr.b/a671-cc-70/a515-50/a135-a/a179-c
stainless steel --- astm 403 304/304l, 316/316l,316ti,321,317l,310s
alloy steel --- astm 234 wp 1/5/9/11/12/22/91
Specification:
nps from 3/4'' to 48'', dn from 20 to 1200,

wt: 2-80mm, sch 40/80/xxs

Surface:

light oiling, black painting

Standard

Specification

A reducer is a type of pipe fitting used to connect pipes of different sizes or diameters. It allows for a smooth transition between two pipes with varying diameters, ensuring the efficient flow of fluid without causing excessive turbulence or pressure drop. They play a critical role in maintaining proper fluid flow and pressure while accommodating changes in pipe size due to system design, process requirements, or equipment connections.

Material

Stainless Steel ASME / ASTM SA / A403 SA / A 774 WP-S, WP-W, WP-WX, 304, 304L, 316, 316L, 304/304L,  316/316L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404

Dimension

ANSI B16.9, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2312, JIS B2313

Thickness

Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.

Size

1/2"~80"


Material

Carbon Steel ASME / ASTM SA / A234 WPB, DIN 1.0405

Dimension

ANSI B16.9, ANSI B16.28, JIS B2312, JIS B2313

Thickness

Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.

Size

1/2"~80"

Packing

  • Iron frame box packing

    Iron frame box packing
